The Influence of Cr Doped TiO2 on the Optical Property and Photocatalytic Activity under Sunlight Irradiation

Abstract

Pure TiO₂ and Cr doped TiO₂ (0.1-1.0wt% Cr) nanoparticles were synthesized via sol gel method. This study focuses on narrowing the TiO₂ band gap energies in order to enhance the photocatalytic efficiency under visible light. The synthesized samples were characterized by X-Ray diffraction method (XRD), field emmision (FESEM) and also UV-Vis diffuse reflectance spectroscopy (DRS). The photocatalytic activity under sunlight irradiation was demonstrated by photocatalytic decomposition of methylene blue in water using UV/Vis spectrophotometer. The XRD analysis of pure TiO₂ and doped TiO₂ calcined at 500^oC showed a mixture of anatase and rutile phases with decreasing crystallites size from 13.3nm to 11.6nm as the concentration of Cr was increased. The anatase-rutile phase transformation increased from 28.8% to 57.4%. An indication shows that at 0.75wt%, Cr the anatase and rutile phases have equal composition percentage. This study demonstrated that band gap energy of TiO₂ was reduced with Cr doping which could enhance the photocatalytic efficiency. Sample containing 1.0wt% exhibit the lowest optical band gap energy at 2.86 eV. The optimum chromium doping concentration was found to be at 0.1 wt% Cr corresponding to band gap energy of 2.87 eV and degradation rate of 84%.
